Graco Proguard + Electrical Surge Protection (24W755)

$398.00

Description

Graco Proguard + Electrical Surge Protection

ProGuard+ is used for the protection of Graco electrical equipment against fluctuations in voltage. If there are excessive voltage fluctuations (high or low) ProGuard+ disconnects the equipment from the power source to reduce the risk of damage to the equipment. ProGuard+ automatically resets after a 60-second delay when acceptable power is available.

High voltage is usually seen when the ProGuard+ is plugged into a power source that is higher than the rated voltage of the equipment. To fix a high voltage issue, use a power source that supplies the correct voltage. Meanwhile, low voltage is usually caused by other equipment being on the same circuit or when operating on generator power which cycles on and off.

Specifications

Nominal voltage: 50/60Hz
Current Rating: 10Amps
High Voltage Disconnect: 280VAC
Low Voltage Disconnect: 170VAC
Reset Time: 60 seconds

Features

Dual-End Voltage Monitoring: Actively protects against both high-voltage spikes (often caused by incorrect power sources) and low-voltage drops (commonly caused by overloaded circuits or cycling generators).

Instant Power Disconnect: Automatically cuts the power supply to the sprayer the moment voltage crosses safe thresholds.

Smart Automatic Reset: Features a built-in 60-second delay timer that automatically reconnects power once stable, acceptable electrical current is restored.

Clear LED Diagnostic Indicators:

Solid Green: System is powered, safe, and functioning normally.
Blinking Red: Fault detected. ProGuard+ has cut power to protect your equipment.

LED Off: No power is reaching the ProGuard+ module.

Inline Plug-and-Play Design: Universal inline connection fits easily between your equipment’s power cord and the jobsite outlet or generator.
