Graco RAC X Switch Tips

Superior Tip Design
' The tip "snaps" in two different positions: spray or reverse.
' Tip is locked securely in guard with the locking tab.
' When using extemely hot solvents, a solvent Seal is available.
' No tools needed to install the OneSeal' tip.

Quick Guide to Understanding Airless Spray Tips: E.g. 517. 5 is the fan size in inches and is doubled (ie. 10 inches). 17 is the orifice size in thousandths of an inch. So a 517 will spray 10 inches wide through an orifice the size of 17 thousandths of an inch. Using that formula, a 413 tip would spray 8 inches wide through an orifice of 13 thousandths of an inch. Choosing the right tip for the right job is crucial!

***DUE TO THE VAST AMOUNT OF DIFFERENT TIP OPTIONS, WE DO NOT CARRY ALL IN STOCK SO PLEASE ALLOW AT LEAST 7 DAYS FOR SHIPPING. PLEASE INQUIRE BEFORE ORDERING IF NEEDED URGENTLY.***

		Fan Width (mm)
Orifice (1/1000 in.)	Flow Lpm	51-102	102-152	152-203	203-254	254-305	305-356	356-406	406-457
.007	.20		207
.009	.33	109	209	309	409	509
.011	.49	111	211	311	411	511	611
.013	.69		213	313	413	513	613
.015	.90	115	215	315	415	515	615
.017	1.15		217	317	417	517	617		817
.019	1.5		219	319	419	519	619		819
.021	1.8		221	321	421	521	621	721	821
.023	2.15			323	423	523	623	723
.025	2.5		225	325	425	525	625
.027	2.96		227	327	427	527	627		827
.029	3.42			329	429	529	629	729
.031	3.90		231	331	431	531	631		831
.033	4.42				433	533	633		833
.035	4.98		235	335	435	535	635	735	835
.037	5.56					537	637
.039	6.18				439	539	639
.041	6.83				441	541	641
.043	7.51				443	543	643
.045	8.23				445	545	645
.047	8.98					547	647
.051	10.67				451	551	651
.055	12.29				455	555	655
.061	15.12					561	661
.065	17.17						665
.071	20.48						671

Water @ 2000 psi (138 bar, 13.8 MPa) - paints with a higher viscosity will decrease the flow rate .

Example: for a tip with a .015 orifice and a 152 mm (6 in) pattern, order LTX315
