Graco Ultra Max II 490PC Pro Stand Unit Electric Powered Airless Sprayer
The new Ultra Max II 490 brings the leading technology and performance of Graco's larger Ultra Max II models into these compact and light weight sprayers. The 490 is the best choice for professionals looking for superior performance and control for daily use on residential jobs.

Makes spraying faster and easier!
- Proven Endurance Pump for exceptional pump life with QuikAccess intake valve to easily clean or clear debris.
- SmartControl 2.0 Pressure Control - advanced microprocessor control delivers a consistent spray fan at all spraying pressures.
- Exclusive Brushless DC Motor - delivers higher horsepower per wall amp.
- Swivel Inlet Suction Hose - solid aluminum construction and no tools removal of hose.
- Easy Out Pump Filter - reduces tip clogs and ensures quality finish.
Units include:
- NEW Contractor Gun
- RAC X 517 SwitchTip and Guard
- 1/4 in x 50 ft (6.4 mm x 15 m) BlueMax II Airless Hose
Specification
Complete with FT x II gun, RAC X Tip, RAC X Guard, 1/4" x 50' (15mtr) Blue Max II Airless Hose & Tools (Shifter & Multi Tool)
0.23" Max Tip / 3,300 psi / 2.0 LPM
1 HP Brushless DC Motor - Lifetime Warranty
Proven Endurance Pump - Long-Life V-Max Blue
Packing, Chromex Rod & Pressure Control - Zero
Digital Pressure Display
Resettable & Life Litre Counter
Swivel Inlet Suction Hose
EasyOut Pump Filter
Portable Lightweight Design - Only 15 kgs.
 |
 |
 |
 |
 |
|
490 PC PRO |
495 PC PRO |
595 PC PRO |
650 PC PRO |
Warranty |
3 years |
3 years |
3 years |
3 years |
Part Numbers: |
Stand 17E887 |
Stand 17E889 Lo-Boy 17E891 Hi-Boy 17E892 |
Lo-Boy 17E897 Hi-Boy 17E896 |
Lo-Boy 26C979 Hi-Boy 19Y424 |
Max. Tip Size |
0.023 |
0.025 |
0.027 |
0.029 |
Maximum bar (psi) |
227 (3300) |
227 (3300) |
227 (3300) |
227 (3300) |
Maximum (lpm) |
2.0 |
2.3 |
2.6 |
3.0 |
Motor Hp |
1.0 MaxPower Brushless |
1.2 MaxPower Brushless |
1.6 MaxPower Brushless |
1.8 MaxPower Brushless |
Weight - Kg |
Stand 15kg |
Stand 15kg Lo-Boy 24kg Hi-boy 27kg |
Lo-Boy 27kg Hi-Boy 27kg |
Lo-Boy 48kg Hi-Boy 48kg |
Pump |
Endurance Piston |
Endurance Piston |
Endurance Piston |
Endurance Piston |
ProConnect |
■ |
■ |
■ |
■ |
Hydraulic Gauge |
■ |
■ |
■ |
|
Digital Display |
|
|
|
■ |
BlueLink System |
■ |
■ |
■ |
|
Control |
SmartControl 3.0 |
SmartControl 3.0 |
SmartControl 3.0 |
SmartControl 3.0 |
Motor |
MaxPower Brushless |
MaxPower Brushless |
MaxPower Brushless |
MaxPower Brushless |
Gun |
Contractor PC |
Contractor PC |
Contractor PC |
Contractor PC |
Hose |
6.4 mm x 15 m (1/4 in x 50 ft) Blue Max II Airless |
6.4 mm x 15 m (1/4 in x 50 ft) Blue Max II Airless |
6.4 mm x 15 m (1/4 in x 50 ft) Blue Max II Airless |
6.4 mm x 15 m (1/4 in x 50 ft) Blue Max II Airless |
Tip |
RAC X LTX 517 - LP 315 |
RAC X LTX 517 - LP 315 |
RAC X LTX 517 - LP 315 |
RAC X LTX 517 - LP 315 |
|
|
|
|
