Graco RAC 5 Switch Tips

Most widely used reversible spray tip. The #1 selling tip on the market!
' Used for commercial and residential paint spraying applications
' Includes the patented OneSeal for most common coatings
' Huge selection of different tip sizes available
' Laser stamped tip size is easy to identify
' Solvent seal available when using extremely hot solvents

Quick Guide to Understanding Airless Spray Tips: E.g. 517. 5 is the fan size in inches and is doubled (ie. 10 inches). 17 is the orifice size in thousandths of an inch. So a 517 will spray 10 inches wide through an orifice the size of 17 thousandths of an inch. Using that formula, a 413 tip would spray 8 inches wide through an orifice of 13 thousandths of an inch. Choosing the right tip for the right job is crucial!

***DUE TO THE VAST AMOUNT OF DIFFERENT TIP OPTIONS, WE DO NOT CARRY ALL IN STOCK SO PLEASE ALLOW AT LEAST 7 DAYS FOR SHIPPING. PLEASE INQUIRE BEFORE ORDERING IF NEEDED URGENTLY.***

		Fan Width (mm)
Orifice (1/1000 in.)	Flow Lpm	51-102	102-152	152-203	203-254	254-305	305-356	356-406	406-457	457-508
.007	.20		207	307
.009	.33	109	209	309	409	509	609
.011	.49	111	211	311	411	511	611
.013	.69	113	213	313	413	513	613
.015	.90	115	215	315	415	515	615		815
.017	1.15		217	317	417	517	617		817	917
.019	1.5	119	219	319	419	519	619		819
.021	1.8	121	221	321	421	521	621	721	821
.023	2.15		223	323	423	523	623	723
.025	2.5		225	325	425	525	625	725
.027	2.96			327	427	527	627		827
.029	3.42				429	529	629	729
.031	3.90			331		531	631		831
.033	4.42				433	533	633		833
.035	4.98		235		435	535	635	735	835	935
.039	6.18				439
.043	7.51				443	543
.045	8.23						645
.051	10.67				451	551
.055	12.29				455	555	655
.063	16.13					563
.065	17.17						665

Water @ 2000 psi (138 bar, 13.8 MPa) - paints with a higher viscosity will decrease the flow rate.

Example: for a tip with a .011 orifice and a 152 mm (6 in) pattern, order 286311
