Graco TexSpray 7900 HD Standard Series Petrol Airless Sprayer (17E841)
$15,900.00

Description

The Graco TexSpray 7900 HD airless texture sprayer delivers the highest performance for the biggest jobs. With maximum flow and extreme durability, this sprayer does it all — skim coat in a Level 5 finish, drywall mud in a variety of finishes, all paints and primers and other heavy coatings.


        Compare Table

        Click here to open table

        		MARK V STD MARK V STD MARK V IRONMAN TEXSPRAY 5900 HD STANDARD TEXSPRAY 7900 HD STANDARD TEXSPRAY 5900 HD PRO TEXSPRAY 7900 HD PRO TEXSPRAY 7900 HD IRONMAN
        Warranty 3 years 3 years 3 years 3 years 3 years 3 years 3 years 3 years
        Part Numbers: 17E657 17E663 17E629 17E839 17E841 17E840 17E842 17E843
        Max. tip size Paint 0.035" Paint 0.035" Paint 0.035" 0.043" 0.047" 0.042" 0.048" 0.047"
        Max. flow - l/min (gpm) 5.1 (1.35) 5.1 (1.35) 5.1 (1.35) 6.0 (1.6) 8.3 (2.2) 6.0 (1.6) 6.0 (1.6) 8.3 (2.2)
        Max. pressure - bar (PSI) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300)
        Motor rating - kW - (HP) 2.1 (2.8) 2.1 (2.8) 2.1 (2.8) 6.5 HP Honda 6.5 HP Honda 6.5 HP Honda 6.5 HP Honda 6.5 HP Honda
        Weight - kg (lbs) 57kg 64kg 59kg 64kg 67kg 70kg 74kg 67kg
        SmartControlTM with ProGuardTM 4.0 4.0 4.0 3.0 3.0 3.0 3.0 3.0
        Hydraulic Pressure Gauge ■ ■ ■ ■ ■ ■ ■
        LED Display
        		■ ■

        		■ ■ ■
        FastFlush 2TM ■ ■ ■




        WatchdogTM
        		■ ■

        		■ ■ ■
        EnduranceTM Pump ■ ■ ■
        		■ ■ ■ ■
        ProConnectTM
        		■ ■ ■ ■ ■ ■ ■
        Piston Rod Chromex MaxLife w/Vortex MaxLife Extreme w/Vortex Chromex MaxLife MaxLife w/Vortex MaxLife w/Vortex MaxLife Extreme w/Vortex
        Sleeve Hardened SST MaxLife MaxLife


        		MaxLife
        MaxFlo 2 ■ ■ ■ ■ ■ ■ ■ ■
        Rock Catcher Std Crush proof Crush proof Standard Standard Crush proof Crush proof Crush proof
        TiltBackTM ■ ■ ■ ■ ■ ■ ■
        QuickReelTM
        		■


        		■ ■
        Flat-Proof Tires

        		■



        		■
        Tips RAC X 427 + 531 RAC X 427 + 531 RAC X 427 + 531 LTX 517 LTX 517 RAC X LTX 517 RAC X LTX 517 RAC X LTX 517
        Guard RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215
        Gun HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605
        Hose Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m BlueMaxTM II 1/4" x 15m - 240797 BlueMaxTM II 1/4" x 15m - 240797 Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m
        Whip hose Blue MaxTM II 1/4" x 0.9mm Blue MaxTM II 1/4" x 0.9m Blue MaxTM II 1/4" x 0.9m (BlueMaxTM II 1/4" X 0.9 M - 241735) (BlueMaxTM II 1/4" X 0.9 M - 241735) Blue MaxTM II 1/4" x 0.9m Blue MaxTM II 1/4" x 0.9m Blue MaxTM II 1/4" x 0.9m
        Tools ■ ■ ■ ■ ■ ■ ■ ■

        Specifications

        CONVERTIBLE - Non-Convertible

        ENGINE BRAND - Honda

        ENGINE SIZE (HP) - 6.5

        ENGINE SIZE (KW) - 4.85

        FEATURE - Endurance Vortex MaxLife Extreme Pump, MaxFlo 2, SmartControl 3.0, Advantage Drive, Honda Engine, Easy Out Filter, Heavy-Duty Prime Valve

        FLUID INLET SIZE (IN) - 1-5/16

        FLUID INLET SIZE (MM) - 33.34

        FLUID INLET THREAD TYPE - UN-2A

        FLUID OUTLET SIZE (IN) - 3/8

        FLUID OUTLET SIZE (MM) - 9.525

        FLUID OUTLET THREAD TYPE - NPSM

        FRAME CONFIGURATION - Hi-Boy

        HOSE INLET DIAMETER (CM) - 0.9525

        HOSE INLET DIAMETER (IN) - 3/8

        HOSE INLET DIAMETER (MM) - 9.525

        INLET PAINT STRAINER - 8 Mesh Stainless Steel Screen

        MAXIMUM FLOW RATE (GPM) - 2.2

        MAXIMUM FLOW RATE (L/MIN) - 8.33

        MAXIMUM SOUND PRESSURE LEVEL (DB(A)). -96

        MAXIMUM TIP SIZE (IN) - 0.048

        MAXIMUM TIP SIZE GUN 1 (IN) - 0.048

        MAXIMUM WORKING PRESSURE (PSI). - 3300

        MAXIMUM WORKING PRESSURE (KPA) - 22700

        POWER RATING (HP) - 6.5

        POWER SOURCE - Gas

        POWER RATING (KW) - 4.85

        POWER RATING (W) - 4847

        MAXIMUM WORKING PRESSURE (MPA) - 22.8

        PRESSURE CONTROL TYPE - SmartControl 3.0

        OVERALL WIDTH (MM) - 620

        MODEL - GMAX II HD

        MAXIMUM WORKING PRESSURE (BAR) - 228

        Features

        Standard Series

        • Endurance MaxLife Piston Pump
          • Lasts 6X longer between repacks
          • Features exclusive hardened MaxLife sleeve and rod
          • Oversized clearances ensure minimal pressure drop

        • MaxFlo 2 with Pack-Out Protection
          • Less pack-out, more productivity
          • Self-cleaning Vibra-Seal Technology eliminates material build-up
          • Continuous spraying with True Pack-Out Protection for more productivity
          • Optimized fluid passageways for the heaviest coatings

        • SmartControl 3.0
          • Consistent spray fan & pressure control
          • Ideal for low overspray applications with the lowest dead band at any pressure

        • Precision Advantage Drive
          • The longest lasting drive
          • Improved jobsite conditions with extremely quiet operation
          • Lifetime Warranty

        • Honda® GX Engine
          • Reliable, Powerful & Easy-to-Start
          • Oil Alert shuts down engine to prevent damage if oil level drops too low

        • Easy Out Pump Filter
          • Easy Pump Maintenance & Less Clogging
          • Inside-out design means less mess with fewer tip clogs

        • Rugged, Durable Cart Design
          • Rugged and easy-to-move
          • Withstands tough jobsite conditions while absorbing impacts and vibrations
          • Easy hose storage with integrated hose wrap and telescoping handle
          • Easy loading with built-in lift handles

        • Heavy-Duty Prime Valve
          • Maintenance-free high-pressure dumping capability

        What's Included

        • Heavy-Duty Blue Texture Gun
          RAC X LTX 427 Spray Tip
          RAC X LTX 531 Spray Tip
          RAC X Guard, 3/8 in x 50 ft BlueMax II Airless Hose
          1/4 in x 3 ft BlueMax II Airless Whip Hose

        Reviews

        Dimensions

        Width
        Width
        Height
        Height
        Length
        Length
        product
        62.00 cm
        102.90 cm
        96.80 cm

        Weight

        Courier

        May require help to carry

        Total Weight: 70.00 kg
