Graco TexSpray 7900 HD Standard Series Petrol Airless Sprayer (17E841)

GRACO

$16,100.00

SKU: 17E841

Quantity

Out of stock

Pay in 4 interest-free payments with

Payment & Security | Refund Policy

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Graco TexSpray 7900 HD Standard Series Petrol Airless Sprayer (17E841)

$16,100.00

Description

GRACO GMAX II 7900 HD 3-in-1 Standard Series Gas Airless Sprayer

The Graco TexSpray 7900 HD Standard Series is the highest-performing petrol airless texture sprayer designed for the most demanding large-scale projects. Engineered for extreme durability, this 3-in-1 unit handles everything from Level 5 skim coats and drywall mud to heavy primers, paints, and protective coatings. It delivers unmatched performance, allowing contractors to use the widest range of tip sizes and longer hose lengths with ease.

Compare Table

Click here to open table


	MARK V STD	MARK V STD	MARK V IRONMAN	TEXSPRAY 5900 HD STANDARD	TEXSPRAY 7900 HD STANDARD	TEXSPRAY 5900 HD PRO	TEXSPRAY 7900 HD PRO	TEXSPRAY 7900 HD IRONMAN
Warranty	3 years	3 years	3 years	3 years	3 years	3 years	3 years	3 years
Part Numbers:	17E657	17E663	17E629	17E839	17E841	17E840	17E842	17E843
Max. tip size	Paint 0.035"	Paint 0.035"	Paint 0.035"	0.043"	0.047"	0.042"	0.048"	0.047"
Max. flow - l/min (gpm)	5.1 (1.35)	5.1 (1.35)	5.1 (1.35)	6.0 (1.6)	8.3 (2.2)	6.0 (1.6)	6.0 (1.6)	8.3 (2.2)
Max. pressure - bar (PSI)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)
Motor rating - kW - (HP)	2.1 (2.8)	2.1 (2.8)	2.1 (2.8)	6.5 HP Honda	6.5 HP Honda	6.5 HP Honda	6.5 HP Honda	6.5 HP Honda
Weight - kg (lbs)	57kg	64kg	59kg	64kg	67kg	70kg	74kg	67kg
SmartControlTM with ProGuardTM	4.0	4.0	4.0	3.0	3.0	3.0	3.0	3.0
Hydraulic Pressure Gauge	■	■	■	■	■	■	■
LED Display		■	■			■	■	■
FastFlush 2TM	■	■	■
WatchdogTM		■	■			■	■	■
EnduranceTM Pump	■	■	■		■	■	■	■
ProConnectTM		■	■	■	■	■	■	■
Piston Rod	Chromex	MaxLife w/Vortex	MaxLife Extreme w/Vortex	Chromex	MaxLife	MaxLife w/Vortex	MaxLife w/Vortex	MaxLife Extreme w/Vortex
Sleeve	Hardened SST	MaxLife	MaxLife				MaxLife
MaxFlo 2	■	■	■	■	■	■	■	■
Rock Catcher	Std	Crush proof	Crush proof	Standard	Standard	Crush proof	Crush proof	Crush proof
TiltBackTM	■	■	■	■	■	■	■
QuickReelTM		■				■	■
Flat-Proof Tires			■					■
Tips	RAC X 427 + 531	RAC X 427 + 531	RAC X 427 + 531	LTX 517	LTX 517	RAC X LTX 517	RAC X LTX 517	RAC X LTX 517
Guard	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215
Gun	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605
Hose	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m	BlueMaxTM II 1/4" x 15m - 240797	BlueMaxTM II 1/4" x 15m - 240797	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m
Whip hose	Blue MaxTM II 1/4" x 0.9mm	Blue MaxTM II 1/4" x 0.9m	Blue MaxTM II 1/4" x 0.9m	(BlueMaxTM II 1/4" X 0.9 M - 241735)	(BlueMaxTM II 1/4" X 0.9 M - 241735)	Blue MaxTM II 1/4" x 0.9m	Blue MaxTM II 1/4" x 0.9m	Blue MaxTM II 1/4" x 0.9m
Tools	■	■	■	■	■	■	■	■
	MARK V STD	MARK V PRO	MARK V IRONMAN	TEXSPRAY 5900 HD STANDARD	TEXSPRAY 7900 HD STANDARD	TEXSPRAY 5900 HD PRO	TEXSPRAY 7900 HD PRO	TEXSPRAY 7900 HD IRONMAN


	MARK V STD	MARK V STD	MARK V IRONMAN	TEXSPRAY 5900 HD STANDARD	TEXSPRAY 7900 HD STANDARD	TEXSPRAY 5900 HD PRO	TEXSPRAY 7900 HD PRO	TEXSPRAY 7900 HD IRONMAN
Warranty	3 years	3 years	3 years	3 years	3 years	3 years	3 years	3 years
Part Numbers:	17E657	17E663	17E629	17E839	17E841	17E840	17E842	17E843
Max. tip size	Paint 0.035"	Paint 0.035"	Paint 0.035"	0.043"	0.047"	0.042"	0.048"	0.047"
Max. flow - l/min (gpm)	5.1 (1.35)	5.1 (1.35)	5.1 (1.35)	6.0 (1.6)	8.3 (2.2)	6.0 (1.6)	6.0 (1.6)	8.3 (2.2)
Max. pressure - bar (PSI)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)	227 (3300)
Motor rating - kW - (HP)	2.1 (2.8)	2.1 (2.8)	2.1 (2.8)	6.5 HP Honda	6.5 HP Honda	6.5 HP Honda	6.5 HP Honda	6.5 HP Honda
Weight - kg (lbs)	57kg	64kg	59kg	64kg	67kg	70kg	74kg	67kg
SmartControlTM with ProGuardTM	4.0	4.0	4.0	3.0	3.0	3.0	3.0	3.0
Hydraulic Pressure Gauge	■	■	■	■	■	■	■
LED Display		■	■			■	■	■
FastFlush 2TM	■	■	■
WatchdogTM		■	■			■	■	■
EnduranceTM Pump	■	■	■		■	■	■	■
ProConnectTM		■	■	■	■	■	■	■
Piston Rod	Chromex	MaxLife w/Vortex	MaxLife Extreme w/Vortex	Chromex	MaxLife	MaxLife w/Vortex	MaxLife w/Vortex	MaxLife Extreme w/Vortex
Sleeve	Hardened SST	MaxLife	MaxLife				MaxLife
MaxFlo 2	■	■	■	■	■	■	■	■
Rock Catcher	Std	Crush proof	Crush proof	Standard	Standard	Crush proof	Crush proof	Crush proof
TiltBackTM	■	■	■	■	■	■	■
QuickReelTM		■				■	■
Flat-Proof Tires			■					■
Tips	RAC X 427 + 531	RAC X 427 + 531	RAC X 427 + 531	LTX 517	LTX 517	RAC X LTX 517	RAC X LTX 517	RAC X LTX 517
Guard	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215	RAC XTM - 246215
Gun	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605	HD Blue Texture - 289605
Hose	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m	BlueMaxTM II 1/4" x 15m - 240797	BlueMaxTM II 1/4" x 15m - 240797	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m	Blue MaxTM II 3/8" x 15m
Whip hose	Blue MaxTM II 1/4" x 0.9mm	Blue MaxTM II 1/4" x 0.9m	Blue MaxTM II 1/4" x 0.9m	(BlueMaxTM II 1/4" X 0.9 M - 241735)	(BlueMaxTM II 1/4" X 0.9 M - 241735)	Blue MaxTM II 1/4" x 0.9m	Blue MaxTM II 1/4" x 0.9m	Blue MaxTM II 1/4" x 0.9m
Tools	■	■	■	■	■	■	■	■
	MARK V STD	MARK V PRO	MARK V IRONMAN	TEXSPRAY 5900 HD STANDARD	TEXSPRAY 7900 HD STANDARD	TEXSPRAY 5900 HD PRO	TEXSPRAY 7900 HD PRO	TEXSPRAY 7900 HD IRONMAN

Specifications

Maximum Flow Rate: 8.33 L/min (2.2 GPM)
Maximum Working Pressure: 3300 PSI (228 bar)
Engine Size: 6.5 HP (4.85 kW) Honda® GX
Maximum Tip Size (1 Gun): 0.048 in
Number of Guns Supported: Up to 4
Weight: 70 kg (153 lb)
Replacement Pump: SKU: 25E689

Features

Endurance™ MaxLife™ Piston Pump: Features an exclusive hardened MaxLife sleeve and rod that lasts 6X longer between repacks.
MaxFlo 2 with Pack-Out Protection: Utilizes self-cleaning Vibra-Seal technology to eliminate material build-up and optimized fluid passageways for the heaviest coatings.
SmartControl™ 3.0: Provides a consistent spray fan and pressure control with the lowest dead band at any pressure, perfect for low overspray applications.
Honda® GX Engine: Reliable 6.5 HP easy-to-start engine equipped with an Oil Alert system to prevent damage if oil levels drop.
Precision Advantage Drive: The longest-lasting drive in the industry, offering extremely quiet operation on the jobsite.
Rugged Cart Design: Includes built-in lift handles, a telescoping handle, and an integrated hose wrap for easy transport and loading.
Easy Out™ Pump Filter: Features an inside-out design to ensure fewer tip clogs and a less messy cleaning process.
Heavy-Duty Prime Valve: Provides maintenance-free, high-pressure dumping capability.
