Graco TexSpray 7900 HD Pro Contractor Series Petrol Airless Sprayer (17E842)

GRACO
Save 1%
$19,830.00
SKU: 17E842

Title

Quantity

Out of stock
Add to Cart
Out of stock
Add to Cart

Payment & Security | Refund Policy

American Express Apple Pay Google Pay Mastercard PayPal Shop Pay Union Pay Visa
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Graco TexSpray 7900 HD Pro Contractor Series Petrol Airless Sprayer (17E842)
$19,830.00

Description

The Graco TexSpray 7900 HD airless texture sprayer delivers the highest performance for the biggest jobs. With maximum flow and extreme durability, this sprayer does it all — skim coat in a Level 5 finish, drywall mud in a variety of finishes, all paints and primers and other heavy coatings.

Compare Table

Click here to open table

MARK V STD MARK V STD MARK V IRONMAN TEXSPRAY 5900 HD STANDARD TEXSPRAY 7900 HD STANDARD TEXSPRAY 5900 HD PRO TEXSPRAY 7900 HD PRO TEXSPRAY 7900 HD IRONMAN
Warranty 3 years 3 years 3 years 3 years 3 years 3 years 3 years 3 years
Part Numbers: 17E657 17E663 17E629 17E839 17E841 17E840 17E842 17E843
Max. tip size Paint 0.035" Paint 0.035" Paint 0.035" 0.043" 0.047" 0.042" 0.048" 0.047"
Max. flow - l/min (gpm) 5.1 (1.35) 5.1 (1.35) 5.1 (1.35) 6.0 (1.6) 8.3 (2.2) 6.0 (1.6) 6.0 (1.6) 8.3 (2.2)
Max. pressure - bar (PSI) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300) 227 (3300)
Motor rating - kW - (HP) 2.1 (2.8) 2.1 (2.8) 2.1 (2.8) 6.5 HP Honda 6.5 HP Honda 6.5 HP Honda 6.5 HP Honda 6.5 HP Honda
Weight - kg (lbs) 57kg 64kg 59kg 64kg 67kg 70kg 74kg 67kg
SmartControlTM with ProGuardTM 4.0 4.0 4.0 3.0 3.0 3.0 3.0 3.0
Hydraulic Pressure Gauge ■ ■ ■ ■ ■ ■ ■
LED Display
■ ■

■ ■ ■
FastFlush 2TM ■ ■ ■




WatchdogTM
■ ■

■ ■ ■
EnduranceTM Pump ■ ■ ■
■ ■ ■ ■
ProConnectTM
■ ■ ■ ■ ■ ■ ■
Piston Rod Chromex MaxLife w/Vortex MaxLife Extreme w/Vortex Chromex MaxLife MaxLife w/Vortex MaxLife w/Vortex MaxLife Extreme w/Vortex
Sleeve Hardened SST MaxLife MaxLife


MaxLife
MaxFlo 2 ■ ■ ■ ■ ■ ■ ■ ■
Rock Catcher Std Crush proof Crush proof Standard Standard Crush proof Crush proof Crush proof
TiltBackTM ■ ■ ■ ■ ■ ■ ■
QuickReelTM
■


■ ■
Flat-Proof Tires

■



■
Tips RAC X 427 + 531 RAC X 427 + 531 RAC X 427 + 531 LTX 517 LTX 517 RAC X LTX 517 RAC X LTX 517 RAC X LTX 517
Guard RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215 RAC XTM - 246215
Gun HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605 HD Blue Texture - 289605
Hose Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m BlueMaxTM II 1/4" x 15m - 240797 BlueMaxTM II 1/4" x 15m - 240797 Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m Blue MaxTM II 3/8" x 15m
Whip hose Blue MaxTM II 1/4" x 0.9mm Blue MaxTM II 1/4" x 0.9m Blue MaxTM II 1/4" x 0.9m (BlueMaxTM II 1/4" X 0.9 M - 241735) (BlueMaxTM II 1/4" X 0.9 M - 241735) Blue MaxTM II 1/4" x 0.9m Blue MaxTM II 1/4" x 0.9m Blue MaxTM II 1/4" x 0.9m
Tools ■ ■ ■ ■ ■ ■ ■ ■

Specifications

COMPATIBLE REPLACEMENT PUMP - 17H837

CONVERTIBLE - Non-Convertible

ENGINE BRAND - Honda

ENGINE SIZE (HP) - 6.5

ENGINE SIZE (KW) - 4.85

FEATURE - Endurance Vortex MaxLife Extreme Pump, MaxFlo 2, SmartControl 3.0, Advantage Drive, ProConnect 2, Flat Proof Tyres, Honda Engine, Easy Out Filter, Heavy-Duty Prime Valve

FLUID INLET SIZE (IN) - 1-5/16

FLUID INLET SIZE (MM) - 33.34

FLUID INLET THREAD TYPE - UN-2A

FLUID OUTLET SIZE (IN) - 3/8

FLUID OUTLET SIZE (MM) - 9.525

FLUID OUTLET THREAD TYPE - NPSM

FRAME CONFIGURATION - Hi-Boy

HOSE INLET DIAMETER (CM) - 0.9525

HOSE INLET DIAMETER (IN) - 3/8

HOSE INLET DIAMETER (MM) - 9.525

INLET PAINT STRAINER - 8 Mesh Stainless Steel Screen

MAXIMUM FLOW RATE (GPM) - 2.2

MAXIMUM FLOW RATE (L/MIN) - 8.33

MAXIMUM SOUND PRESSURE LEVEL (DB(A)). -96

MAXIMUM TIP SIZE (IN) - 0.048

MAXIMUM TIP SIZE GUN 1 (IN) - 0.048

MAXIMUM WORKING PRESSURE (PSI). - 3300

MAXIMUM WORKING PRESSURE (KPA) - 22700

POWER RATING (HP) - 6.5

POWER SOURCE - Gas

POWER RATING (KW) - 4.85

POWER RATING (W) - 4847

MAXIMUM WORKING PRESSURE (MPA) - 22.8

PRESSURE CONTROL TYPE - SmartControl 3.0

OVERALL WIDTH (MM) - 620

MODEL - GMAX II HD

MAXIMUM WORKING PRESSURE (BAR) - 228

Features

  • Endurance Vortex MaxLife Piston PumpSuperior pump life
    • Breakthrough vortex rotating rod technologyLasts 6X longer between repacks with innovative MaxLife technologyOversized passages for high velocity flow to rotate piston for even wear Longest life packings and piston rod Long life ceramic and stainless steel balls included for maximum versatility

  • MaxFlo 2 with Pack-Out Protection
    • Less pack-out, more productivity
    • Self-cleaning Vibra-Seal Technology eliminates material build-up
    • Continuous spraying with True Pack-Out Protection for more productivity
    • Optimized fluid passageways for the heaviest coatings

  • SmartControl 3.0
    • Consistent spray fan & pressure control
    • Ideal for low overspray applications with the lowest dead band at any pressure

  • Precision Advantage Drive
    • The longest lasting drive
    • Improved jobsite conditions with extremely quiet operation
    • Lifetime Warranty

  • Honda® GX Engine
    • Reliable, Powerful & Easy-to-Start
    • Oil Alert shuts down engine to prevent damage if oil level drops too low

  • Easy Out Pump Filter
    • Easy Pump Maintenance & Less Clogging
    • Inside-out design means less mess with fewer tip clogs

  • Rugged, Durable Cart Design
    • Rugged and easy-to-move
    • Withstands tough jobsite conditions while absorbing impacts and vibrations
    • Easy hose storage with integrated hose wrap and telescoping handle
    • Easy loading with built-in lift handles

  • Heavy-Duty Prime Valve
    • Maintenance-free high-pressure dumping capability
    • Crushproof Inlet Strainer
      • Durable filtration
      • Stands up to harsh impacts to maintain even flow through filter
    • ProConnect 2 Pump Replacement System
      • Eliminate costly downtime
      • Exchange pump in minutes
      • No tools, pins or parts to lose
    • QuikReel Hose Management System
      • Easy hose management
      • Deploy and rewind up to 300 feet of hose in seconds
      • No twisting, kinking, and coiling
      • Use only the hose you need — the rest stays on the reel
    • LED Display
      • Easy-to-read display provides quick reference to show:
        • Pressure read-out
        • Job/lifetime/gallon counter
        • Self-diagnostics

    Reviews

    Dimensions

    Width
    Width
    Height
    Height
    Length
    Length
    product
    62.00 cm
    96.50 cm
    84.60 cm

    Weight

    Courier

    May require help to carry

    Total Weight: 76.00 kg
