Graco G-Force II 4040 HC-DD 4000 PSI Pressure Washer (25N682)

Graco G-Force II 4040 HC-DD 4000 PSI Pressure Washer (25N682)

GRACO

$5,379.00

SKU: 25N682

Quantity

Out of stock

Pay in 4 interest-free payments with

Payment & Security | Refund Policy

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Graco G-Force II 4040 HC-DD 4000 PSI Pressure Washer (25N682)

$5,379.00

Description

Graco G-Force II 4040 HG-DD 4000 PSI Pressure Washer

The Graco G-Force II™ 4040 HG-DD is a heavy-duty, commercial-grade pressure washer built to handle demanding daily workloads, structural property maintenance, and large-scale contractor projects. Engineered to comfortably sustain over 30 hours of rigorous cleaning operation per week, this machine delivers a devastating combination of high fluid volume and raw scouring pressure in a highly maneuverable, lightweight configuration.

By using a highly efficient Direct Drive (DD) transmission layout, the water pump is bolted directly to the primary drive shaft of the engine. This alignment eliminates secondary pulleys, tension belts, and extra structural components, delivering a lighter, more compact, and low-maintenance profile that fits easily onto utility trucks and service vans.

Graco G-Force II Brochure

Compare Table

Click here to open table


	3325 HA-DD	3230 HA-DD	4040 HG-DD	4040 HC-DD	4040 HG-BD	4040 HC-BD	4240 KA-DD	4240 HA-DD
Part Numbers:	25N638	25N639	25N681	25N682	25N683	25N684	25N640	25N641
Max Pressure - bar (PSI)	227 (3300)	220 (3200)	275 (4000)	275 (4000)	275 (4000)	275 (4000)	290 (4200)	290 (4200)
Max. flow - l/min (gpm)	9.46 (2.5)	11.36 (3)	15.14 (4)	15.14 (4)	15.14 (4)	15.14 (4)	15 (4)	15 (4)
Engine displacement - cm3	200	270	390	390	390	390	429	390
Pump	AR Brass Triplex	AR Brass Triplex	GP Brass Triplex	CAT Brass Triplex	GP Brass Triplex	CAT Brass Triplex	AR Triplex Plunger	AR Triplex Plunger
Weight - kg (lbs)	30.4 (67)	37.2 (82)	58.5 (129)	60.3 (133)	72.1 (159)	71.6 (158)	47 (104)	46 (102)
SmartControlTM with ProGuardTM	4.0	4.0	4.0	3.0	3.0	3.0	3.0	3.0
Gardena® Connection	■	■	■	■	■	■	■
Chemical injector	Integrated	Integrated	■	■	■	■	■	■
Direct Driven	■	■	■	■			■	■
Belt Driven					■	■
Adjustable Unloader	Integrated	Integrated	External	External	External	External	Integrated	External
Easy Start Pressure Relief		■	■	■	■	■	■	■
Light Weight Aluminium Frame		■	■	■	■	■	■	■
Thermo-sensor	■	■	■	■	■	■	■
Cold Water	■	■	■	■	■	■	■	■
Tips	0° - 805591 / 15° - 805592 / 25° - 805593 / chemical tip - 805634	0° - 805591 / 15° - 805592 / 25° - 805593 / chemical tip - 805634	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546
Gun	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784
Filter (mesh)	50	50	50	50	50	50	50	50
Hose	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 24478315m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783
Engine oil	■	■	■	■	■	■	■	■
	3325 HA-DD	3230 HA-DD	4040 HG-DD	4040 HC-DD	4040 HG-BD	4040 HC-BD	4240 KA-DD	4240 HA-DD


	3325 HA-DD	3230 HA-DD	4040 HG-DD	4040 HC-DD	4040 HG-BD	4040 HC-BD	4240 KA-DD	4240 HA-DD
Part Numbers:	25N638	25N639	25N681	25N682	25N683	25N684	25N640	25N641
Max Pressure - bar (PSI)	227 (3300)	220 (3200)	275 (4000)	275 (4000)	275 (4000)	275 (4000)	290 (4200)	290 (4200)
Max. flow - l/min (gpm)	9.46 (2.5)	11.36 (3)	15.14 (4)	15.14 (4)	15.14 (4)	15.14 (4)	15 (4)	15 (4)
Engine displacement - cm3	200	270	390	390	390	390	429	390
Pump	AR Brass Triplex	AR Brass Triplex	GP Brass Triplex	CAT Brass Triplex	GP Brass Triplex	CAT Brass Triplex	AR Triplex Plunger	AR Triplex Plunger
Weight - kg (lbs)	30.4 (67)	37.2 (82)	58.5 (129)	60.3 (133)	72.1 (159)	71.6 (158)	47 (104)	46 (102)
SmartControlTM with ProGuardTM	4.0	4.0	4.0	3.0	3.0	3.0	3.0	3.0
Gardena® Connection	■	■	■	■	■	■	■
Chemical injector	Integrated	Integrated	■	■	■	■	■	■
Direct Driven	■	■	■	■			■	■
Belt Driven					■	■
Adjustable Unloader	Integrated	Integrated	External	External	External	External	Integrated	External
Easy Start Pressure Relief		■	■	■	■	■	■	■
Light Weight Aluminium Frame		■	■	■	■	■	■	■
Thermo-sensor	■	■	■	■	■	■	■
Cold Water	■	■	■	■	■	■	■	■
Tips	0° - 805591 / 15° - 805592 / 25° - 805593 / chemical tip - 805634	0° - 805591 / 15° - 805592 / 25° - 805593 / chemical tip - 805634	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546	0° - 805591 / 15° - 805592 / 25° - 805593 / 40° - 805546 / chemical tip - 805634 / 40° - 805546
Gun	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784	90cm + QDs - 244784
Filter (mesh)	50	50	50	50	50	50	50	50
Hose	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 24478315m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783	15m + QDs - 244783
Engine oil	■	■	■	■	■	■	■	■
	3325 HA-DD	3230 HA-DD	4040 HG-DD	4040 HC-DD	4040 HG-BD	4040 HC-BD	4240 KA-DD	4240 HA-DD

Specifications

Part Number: 25N682 (Model: G-Force II 4040 HG-DD)
Operational Grade: Commercial / Large Property Maintenance / Remodeler
Maximum Fluid Pressure: 4000 PSI (275 bar)
Maximum Flow Rate: 15 LPM (Approx. 4.0 GPM)
Total Cleaning Power Index: 16,000 Cleaning Units (PSI * GPM)
Engine Platform: Honda GX390 OHV with Oil Alert
Pump Platform: CAT® Industrial Triplex Plunger Pump
Transmission Style: Direct Drive (Pump RPM matches Engine RPM)
Chassis Material: Lightweight Heavy-Gauge Structural Aluminum
System Dry Weight: 99 kg
Hose Profile: 0.95 cm (3/8 in) ID x 15 m (50 ft) Non-Marking Rubber
Nozzle Orifice Base: 4.0 Fixed Orifice Quick-Disconnect

Features

The Engine (Honda GX390): Driven by an industry-standard, commercial-grade Honda GX series engine. Known worldwide for first-pull reliability, exceptional fuel economy, cast-iron cylinder sleeve durability, and an extensive global service support footprint.
The Water Pump (CAT Triplex Plunger Pump): Equipped with a premier professional-tier CAT Triplex plunger pump featuring a forged brass manifold. This design disperses heat far more efficiently than standard stainless steel caps, significantly extending the life of your high-pressure fluid packing seals.
Rust-Proof Aluminum Frame: Features Graco's signature aircraft-grade aluminum frame chassis, making it vastly lighter to lift than steel frames, entirely rust-proof, and easy to maneuver across rugged jobsites.
Professional 19mm Axle Infrastructure: Engineered with a heavy-duty 19mm steel axle rod that resists bending under impact, keeping the heavy pneumatic tires square and rolling smoothly over curbs and debris.
Adjustable External Bypass Unloader: Features an external pressure unloader with an built-in EZ Start pressure release loop. The external bypass structure channels trapped water away from the pump head while idling, allowing the fluid to run significantly cooler to provide superior defense against thermal pump overheating during long stops and starts.
Premium Flexible Delivery Kit: Arrives completely ready to work with a heavy-duty 15-meter (50 ft) non-marking grey braided pressure hose, a professional-grade 91 cm (36 in) steel lance, and standard dual-ended quick-connect couplers.
